Learn NinjaScript: Detecting Crosses, Flips, and Directional Shifts

ByJack | MyDailyTake Reading Time: 5 minutes
Part of the Learn NinjaScript course. A free, structured path from your first indicator to machine learning — see all lessons →

You have an SMA. You want to know when price crosses it — that’s a signal. You also want to know when the SMA itself changes direction — that’s a different signal, same class of problem. Both come down to comparing current and previous values, and NinjaScript has built-in helpers for the common case plus straightforward patterns for the custom one.

This post covers three patterns: CrossAbove / CrossBelow for standard crosses, rolling your own cross detection when the built-ins don’t fit, and the slope-flip and “fire only once” flag patterns that layer on top.

⚙️ CrossAbove and CrossBelow Built-ins

NinjaScript ships two helpers for the most common cross case: one series crossing another. CrossAbove(series1, series2, lookBackPeriod) returns true if series1 crossed above series2 within the last lookBackPeriod bars. CrossBelow is the mirror.

// Fires true on bars where Close crossed above SMA within the last 1 bar.
if (CrossAbove(Close, SMA(Period), 1))
{
    Draw.ArrowUp(this, "cross_" + CurrentBar, false, 0,
                 Low[0] - TickSize * 2, Brushes.LimeGreen);
}

The lookBackPeriod matters. 1 is “crossed on this bar” — what you almost always want for arrow signals. Larger values return true for the full N-bar window after a cross — useful for “recently crossed” logic but prone to multi-firing if you aren’t guarding elsewhere. Default to 1 unless you have a specific reason.

Both helpers accept anything that looks like a price series — Close, High, an indicator like SMA(Period), or a custom Series<double> you built yourself. The pattern scales to “my custom series crossed above another custom series” without writing new code.

🎯 Rolling Your Own Cross Detection

The built-ins expect two series. When one side of the cross is a constant, a computed threshold, or something that isn’t series-shaped, you compare current and previous values directly:

// "Close crossed above 4500" — threshold isn't a series, so we compare manually.
double threshold = 4500;
bool crossedAbove = Close[0] > threshold && Close[1] <= threshold;

if (crossedAbove)
{
    // Fires exactly once, on the bar that crossed.
}

Two things the manual form gets right that you might get wrong if you’re not careful. First, the previous-bar comparison is <=, not < — a bar that touched the threshold exactly doesn’t count as “already above.” Second, the previous bar access [1] requires CurrentBar >= 1; guard with if (CurrentBar < 1) return; or similar at the top of OnBarUpdate.

↕️ Direction-Change Detection

A direction flip on a line — “the SMA was rising, now it’s falling” — isn’t a cross between two series. It’s a change in the sign of the slope. The pattern uses three consecutive values:

if (CurrentBar < Period + 2) return;

double current  = SMA(Period)[0];
double previous = SMA(Period)[1];
double twoBack  = SMA(Period)[2];

bool wasUp  = previous > twoBack;
bool nowUp  = current  > previous;
bool flipped = wasUp != nowUp;

The variable names do the work of documentation here. The flip is simply “was up vs. is up doesn’t match.” You can extend the same pattern to a flatter slope definition — “was rising by at least N ticks per bar” — by comparing (previous - twoBack) against a threshold rather than just checking sign.

🚩 Flip Flag Pattern

The previous section’s flipped is true only on the flip bar. For a strategy or another indicator to read “did a flip happen on this bar or any bar in recent history,” expose it as a Series<bool>:

private Series<bool> sDirectionFlip;

protected override void OnStateChange()
{
    // ... SetDefaults ...
    if (State == State.DataLoaded)
        sDirectionFlip = new Series<bool>(this, MaximumBarsLookBack.Infinite);
}

protected override void OnBarUpdate()
{
    if (CurrentBar < Period + 2) return;

    double current  = SMA(Period)[0];
    double previous = SMA(Period)[1];
    double twoBack  = SMA(Period)[2];

    bool wasUp = previous > twoBack;
    bool nowUp = current  > previous;

    sDirectionFlip[0] = wasUp != nowUp;
}

[Browsable(false)][XmlIgnore]
public Series<bool> DirectionFlip
{
    get { Update(); return sDirectionFlip; }
}

A strategy reading mySma.DirectionFlip[0] gets true only on the bar where direction changed. [3] gives three bars ago. The Series handles the history; your flip-detection code runs once per bar and stores the answer.

Cross Detection Patterns

What You Are Detecting Pattern Notes
Series crossing another series CrossAbove(a, b, 1) or CrossBelow(a, b, 1) Default lookBack of 1. Larger values multi-fire for N bars after a cross.
Series crossing a constant or computed threshold current > threshold && previous <= threshold (manual) Guard with CurrentBar >= 1 before accessing previous.
Line or Series changing direction Compare slope sign across three consecutive values Guard with CurrentBar >= Period + 2 to avoid fake flips at chart start.
Exposing flip history for strategies Write the flip bool into a Series each bar Use MaximumBarsLookBack.Infinite; mark [Browsable(false)][XmlIgnore].

📝 Pitfalls Checklist

  • Using == on floating-point values. Close[0] == SMA[0] is almost never true in practice. Always use the cross comparison pattern (strict current, inclusive previous).
  • Forgetting the lookBackPeriod on CrossAbove/CrossBelow. Values greater than 1 return true for multiple bars after a cross. Use 1 unless you want multi-fire behavior.
  • Triggering on every bar of sustained direction. If you wrote if (Close[0] > SMA[0]) thinking it was a cross, you got every bar above the SMA, not just the cross bar. The cross form requires BOTH current above AND previous at or below.
  • Not guarding Value[1] or Series[1] access. At bar 0 there is no previous bar. Guard with if (CurrentBar < 1) return; before any bars-ago-1 access.
  • Using CrossAbove with a Series that resets bars. Reset bars on a Series<double> are technically “invalid data.” If CrossAbove reads across a reset boundary, the result depends on how the helper treats invalid slots. Test with your own cross-detection pattern for full control.
  • Slope flip fired on the first plot bar. The two-back comparison needs CurrentBar >= Period + 2. Without that guard you get a fake flip at the start of the chart.
